LZY-W concrete concrete forming machine

1. Features and Benefits:

     LZY-W is to improve the utilization of machinery, expand the user product structure, the company with more than 20 years of practical experience, set all models of long function, the successful development of multi-functional molding machine, and won the national invention patents.

     High-speed vibration, three-stage servo hydraulic molding, fine road forming process to effectively protect the natural material (stone, sand) intact without loss of a high degree of automation, automatic feeding plate automatic feeding an automatic stripping an automatic output The components produced by the external light, antifreeze, impermeability good.

2. Production range and efficiency:

     ① D20 ~ D140U type, ladder channel components; Taiwan when the output 80-120 pieces:

     ② cable trough components and cover; production per l-l0 pieces, Taiwan when the output of 100-150 pieces.

     ③ lOOkg within the road along the stone, rectangular, shaped, hexagonal block, hollow, solid building blocks and so on.

3. power:

     Machine power a total of 18.75kw, which host 11kw, shaking table 2.2kw × 2, for the machine 1.5kw, pad conveyor 1.1kw, pieces of machine 0.75kw.
